SoundCompass: Navigating Target Sound Extraction with
Effective Directional Clue Integration in Complex Acoustic Scenes

Dayun Choi and Jung-Woo Choi

School of Electrical Engineering, KAIST, Daejeon, Republic of Korea

{cdy3773, jwoo}@kaist.ac.kr

Abstract

Recent advances in target sound extraction (TSE) utilize directional clues derived from direction of arrival (DoA), which represent an inherent spatial property of sound available in any acoustic scene. However, previous DoA-based methods rely on hand-crafted features or discrete encodings, which lose fine-grained spatial information and limit adaptability. We propose SoundCompass, an effective directional clue integration framework centered on a Spectral Pairwise INteraction (SPIN) module that captures cross-channel spatial correlations in the complex spectrogram domain to preserve full spatial information in multichannel signals. The input feature expressed in terms of spatial correlations is fused with a DoA clue represented as spherical harmonics (SH) encoding. The fusion is carried out across overlapping frequency subbands, inheriting the benefits reported in the previous band-split architectures. We also incorporate the iterative refinement strategy, chain-of-inference (CoI), in the TSE framework, which recursively fuses DoA with sound event activation estimated from the previous inference stage. Experiments demonstrate that SoundCompass, combining SPIN, SH embedding, and CoI, robustly extracts target sources across diverse signal classes and spatial configurations.

Model Architecture

overall_architecture
Fig. 1. (a) Overall architecture of SoundCompass for DoA-based target sound extraction and (b) details of a fusion module including a Spectral Pairwise INteraction (SPIN) module and integrating directional clue by feature-wise linear modulation (FiLM) for $K$ subbands.

CoI_architecture
Fig. 2. Details of iterative refinement.

Performance Comparisons

Table. 1. Performance comparisons across models and structural variations of the proposed methods.
experimental result

t-SNE Trajectories

tSNE trajectories
Fig. 3. The t-SNE trajectories of the FiLM scale ($\gamma$) parameters across three subbands, with respect to azimuth (top, for 5 fixed elevations) and elevation (bottom, for 5 fixed azimuths).

Three Audio Samples

Click a toggle to listen to samples.
All spectograms are the first channel of microphone array.

Sample #1

Extraction of each audio from the mixture including 4 sources

SI-SNRi Contour Maps

SI-SNRi contour maps

Input Mixture and Sum of Direct/Reverb Components from Direct/Reverb Audio Decoder

Input Mixture
Input Mixture
Source 1
($\theta=$116°, $\phi=$130°)
Ground truth
GT of source 1
Source 2
($\theta=$89°, $\phi=$77°)
Ground truth
GT of source 2
Source 3
($\theta=$63°, $\phi=$60°)
Ground truth
GT of source 3
Source 4
($\theta=$77°, $\phi=$273°)
Ground truth
GT of source 4
Estimation
EST of source 1
Estimation
EST of source 2
Estimation
EST of source 3
Estimation
EST of source 4
Direct Components of Above Samples from Direct Audio Decoder
Ground truth (direct)
GT of source 1
Ground truth (direct)
GT of source 2
Ground truth (direct)
GT of source 3
Ground truth (direct)
GT of source 4
Estimation (direct)
EST of source 1
Estimation (direct)
EST of source 2
Estimation (direct)
EST of source 3
Estimation (direct)
EST of source 4
Sample #2

Extraction of each audio from the mixture including 5 sources

SI-SNRi Contour Maps

SI-SNRi contour maps

Input Mixture and Sum of Direct/Reverb Components from Direct/Reverb Audio Decoder

Input Mixture
Input Mixture
Source 1
($\theta=$105°, $\phi=$334°)
Ground truth
GT of source 1
Source 2
($\theta=$55°, $\phi=$41°)
Ground truth
GT of source 2
Source 3
($\theta=$85°, $\phi=$330°)
Ground truth
GT of source 3
Source 4
($\theta=$72°, $\phi=$155°)
Ground truth
GT of source 4
Source 4
($\theta=$96°, $\phi=$197°)
Ground truth
GT of source 5
Estimation
EST of source 1
Estimation
EST of source 2
Estimation
EST of source 3
Estimation
EST of source 4
Estimation
EST of source 5
Direct Components of Above Samples from Direct Audio Decoder
Ground truth (direct)
GT of source 1
Ground truth (direct)
GT of source 2
Ground truth (direct)
GT of source 3
Ground truth (direct)
GT of source 4
Ground truth (direct)
GT of source 5
Estimation (direct)
EST of source 1
Estimation (direct)
EST of source 2
Estimation (direct)
EST of source 3
Estimation (direct)
EST of source 4
Estimation (direct)
EST of source 5
Sample #3

Extraction of each audio from the mixture including 5 sources

SI-SNRi Contour Maps

SI-SNRi contour maps

Input Mixture and Sum of Direct/Reverb Components from Direct/Reverb Audio Decoder

Input Mixture
Input Mixture
Source 1
($\theta=$80°, $\phi=$315°)
Ground truth
GT of source 1
Source 2
($\theta=$75°, $\phi=$47°)
Ground truth
GT of source 2
Source 3
($\theta=$100°, $\phi=$131°)
Ground truth
GT of source 3
Source 4
($\theta=$130°, $\phi=$248°)
Ground truth
GT of source 4
Source 4
($\theta=$75°, $\phi=$118°)
Ground truth
GT of source 5
Estimation
EST of source 1
Estimation
EST of source 2
Estimation
EST of source 3
Estimation
EST of source 4
Estimation
EST of source 5
Direct Components of Above Samples from Direct Audio Decoder
Ground truth (direct)
GT of source 1
Ground truth (direct)
GT of source 2
Ground truth (direct)
GT of source 3
Ground truth (direct)
GT of source 4
Ground truth (direct)
GT of source 5
Estimation (direct)
EST of source 1
Estimation (direct)
EST of source 2
Estimation (direct)
EST of source 3
Estimation (direct)
EST of source 4
Estimation (direct)
EST of source 5
